Physical Info
Device Dimensions：10.1'' x 11.4'' x 4.2''(257 mm×291 mm×106 mm)
Weight：5.5 lb (2.5 kg)
Display：8.0-inch TFT LCD with touchable screen
Model：Biocare iE6
Tech Spec
Acquisition Mode：Simultaneous standard 12-lead
Lead Mode：Standard 12 leads, Cabrera
HRV：Heart Rate Variability acquisition and review
Sampling Rate：8,000 samples/second/channel
Heart Rate Range：30 bpm~300 bpm
Acquisition Time：10~24 seconds
A/D Conversion：24 bits
Frequency Response：0.05Hz～250Hz
Patient Type：
Adults (older than 12 years old);
Pediatrics (age: 29 days - 12 years old);
Neonates (infants born less than 28 days)
Filter：
EMG filter: 25/35/75/100/150/250 Hz
Baseline wander filter: 0.01/0.02/0.05/0.35/0.5/0.8 Hz
AC filter: 50/60 Hz
Common Mode Rejection Ratio (CMRR)：
>110dB (AC filter on)
>100dB (AC filter off)
Alarm Prompt：
Lead-off detection, lead overflow, AC interference, baseline wander interference, EMG interference
ECG Interpretation：Biocare CardioPro ECG analysis program for adults and pediatrics
Waveform Freeze：Up to 300 seconds
Rhythm Analysis：
Single rhythm mode: 30-300 seconds
Three rhythms mode: 30-100 seconds for each lead
Measurement Parameters：
Ventricular Rate, PR Interval, QRS Time Limit, QT/QTC Interval, P/QRS/T Axis, RV5/SV1 Amplitude and RV5+SV1 Amplitude
Recording Paper：Z- fold paper, 112mm×140mm - 160P
Record Format：
Standard leads: 3×4, 3×4+1R, 3×4+3R, 6×2, 6×2+1R, 1×12+1R;
Nehb lead: 6×1, 3×2;
Record Mode：Auto, Manual, Upload, Cycle, Trigger
Papwr Speed：(5, 6.25, 10, 12.5, 25, 50) mm/s ±5%
Power Supply
DC Power Supply：Rechargeable lithium battery, 14.8V, 2200mAh
Battery Running Time：3-hour continuous operating
Battery Charging Time：4 hours
AC Power Supply：100V-240V, 50Hz/60Hz, 80VA
Input & Output
Communication with Biocare ECG-1000 software on PC with Microsoft Windows XP/Win7/Win8/Win10 operating systems, Vista in 32/64 bits.
Input：Touch screen, Support external scanner
Data Storage：≥3500 ECG files (when the ECG acquisition time is 10 seconds ), support external SD card, USB 2.0 drive
Data Format：ECG, XML, JPEG, DICOM, PDF
loT：Support TCP, FTP, HL7 protocol via LAN or WIFI
Packing List
Main ECG Unit
Patient Lead Wire (1 set)
Limb Clamp Clip (1 set)
Chest Suction Ball (1 set)
ECG Snap-Clip Adapters (10 pieces)
Disaposable Electrodes (10 pieces)
Power Cables (US & EU Standard)
AC Power Adaptor
Equipotential Grounding Cable
Thermal Recording Grid Paper (z-fold paper)
User Manual
Qualified Certificate
