Can Cooling Down Quickly~~~!!!

COMPATIBILITY:

Core Size:           20.7" *25.5" *1.02"(525*648*26mm)

Rows:                 1

Inlet/Outlet:        1.38"/1.38"(35/35mm)

Trans Cooler:       Included(￠26*425*M14*1.5)

(Please check the model list in order to fit your vehicle)

RADIATOR SIZE:

1995-2004 Toyota Tacoma 2.7L

1995-2004 Toyota Tacoma 2.4L

1995-2004 Toyota Tacoma 3.4L

Package include: 1 piece Aluminum Radiator in Cartoon Box+ Radiator Cap

(Please double confirm your radiator measurements before ordering)

BEFORE YOU BUY, PLEASE MAKE SURE THE FOLLOWING POINTS:

1.Compare car part with picture on our website
2. Make sure our goods is suitable for your car
3. Compare core size, overall size, inlet outlet size etc
4. Anything unclear, please don’t hesitate to contact our custom service

RADIATOR ADVANTAGE

*INCREASED cooling capacity & LOWER temperature( 35 - 45% )

*DIRECT Bolt-On OE Fitment or Replacement

* LESS weight & MORE resistant

*1 YEAR Warranty Against Manufacturing Defect

*TUBE and FIN design & FULL T-6061 aluminum

*EXTRA thickness of bracket and tubes to maintain constant geometry at ALL times.

* IMPROVE handling, stability at high speed and cornering, hence safer driving.

* Minimize the weight transfer of the vehicle body, BETTER traction during cornering.

*LUXERAD aluminum radiator is designed to provide maximum cooling

efficiency to PREVENT premature engine failure.

HOW TO REPLACE THE RADIATOR:

1. Disconnect the battery.

2. Drain the radiator fluid into a suitable container.

3. Remove the old radiator:

 -Take off any plastic covers around the radiator.

 -Disconnect the electrical connector to the fan, and unbolt and remove the fan assembly.

 -Disconnect the radiator hoses from the radiator.

 -Disconnect the transmission cooling lines from the bottom of the radiator.

 -Remove any clamps, brackets, or screws holding the radiator inside its frame.

 -Lift the radiator up and out of the car.

4. Install the new radiator:

 -Slide the new radiator into place.

 -Connect any clamps or brackets that hold the radiator in place.

 -Connect the transmission cooling lines carefully.

 -Connect the engine cooling hoses to the radiator.

 -Replace the fan and fan shroud.

 -Reconnect the fan electrical connection.

 -Replace the plastic covers.

5. Fill the radiator with fluid.

6. Check your work to make sure that there are no leaks.

(Tools need to be prepared: Screwdrivers, Wrenches, Drain pan)

Note: Do please keep children and pets away when replacing the radiator)

NOTE:

1. Project operation, the vehicle normal temperature 60 to 80 degrees.

2. Add detergent if the tank is too full can take some antifreeze.

HOW TO CLEAN RADIATOR:

1. Start the vehicle, to rise to normal temperature. Slowly open the tank

cover, the fluid shake from the tank after filling the mouth, the cleaner can

be mixed with any brand of coolant. Idle running not less than 15 minutes,

not cleaning vehicles not less than 30 minutes for two years. And then discharge

coolant, flush water tank, until out of clear water, suitable for any water cycle system.

2. After cleaning, after waiting for pipeline rehabilitation add fluid to water tank,

and inject new coolant and water purification.

SHIPMENT

Our shipment is divided into two warehouses:  City of Industry- CA , NY ect.

According to your address, we will choose the nearest warehouse to deliver the goods to you in the fastest way.

All orders will be sent within one business day after payment received. Carrier : UPS ground

We do not ship to P.O. Box, APOs, FPOs, or Military Mail Box. CAN'T SHIP TO HI,VI,AK,PR,GU and so .
