Features:
*With camera, the light source: Parallel to the LED adjustable light.
*It can connect computers, endoscopes, monitors, televisions.
*New design fiber optic upright projection system, projection lighting scope is adjustable to meet different viewing field along with magnification changed
*It is featured for flexible handling and easy operation.
*Adjust eyepiece position arbitrarily according to operating environment and posture.
*Unique 10X magnification design, broad and bright vision.
*It can be connected to the center pillar of the dental chair. It is very convenient to use. Usually the diameter is 45MM. Please contact us if you need it for 50mm.
*It is sued for micro-operation in dental especially,and can be used for micros-operation in ophthalmology,ear-nose-throat,gynecology and surgery.
Microscope parameters:
*Eyepieces: Binoculars 10X 15B(Aperture: 15mm)
*Dubleey epiece tube:Pupildistance adjustment rang :55mm-80mm
*Eyepiece:Field of vision adjustment :±7D
*Big objective lens:F=250mm
*Object diameter:LED light source>45,000LX
*View diameter: 10mm-100mm
*Spot diameter: 90mm
*Balance arm:Down: 240mm, Middle: 450mm, Up: 230mm
*Microscope light source: Balance the light source, light color:white and orange
*Maximum resolution:1920*1080P
*Camera Magnification Ratio:2.5X-25X (Continuous Zoom)
*Camera pixel: 1600W
*Working distance: about 250mm
*Manual continuous regulation.
*Display method system: software display or IOS system software
*Maximum resolution: Full HD 1920*1080P
*Power supply: AC220V 50HZ/AC110V 60HZ
Packing list:
Microscope body*1
Eyepiece*2
Camera*1
Adapter*1
0.5 Object lens*1
Handle*2
Light Source*1
Bracket*1
Mechanical arm*1
Fixture*1
USB cable*1
Power cord*2
