Package include:
1 Set Fiber Laser Marking Machine
1 Pcs U Disk (USB)
1 Pcs Data Line
1 Software Lightburn
1 Set Foot Switch
1 Set Assembly Tools
4 pcs Fixed Sheet Metal
1 Set Power Cable
10 Pcs Metal Card
Pls note:
The marking area is optional : 50x50 / 70x70 / 110x110 / 150x150 / 200x200 / 220x220 / 300x300mm,
we ship 150x150mm lens as default, U can also leave messenger to choose other size after placing the order,thank u for ur understanding.
The default voltage in the United States is 110V, while in Europe it is 220V. Alternatively, the required voltage can be noted when placing an order
We also have JPT MOPA lasers, please contact us if needed
If you need a board for EZCAD2 software, please contact customer service
Thank you
Model | FDF-10 |
Fiber Laser power | 20W/30W/50W |
Fiber Laser Brand | RAYCUS |
WorkingArea/Length | 150*150mm(Optional100MM/200MM/300MM. |
Galvanometer | RC1001 (Double Red light Align Version) |
Field Mirror | F200(150MM)/Optional:F160(110MM)/F290(200MM)/F430(300MM) |
Power supply | MeanWell (Original) |
Cooling Mode | Air Cooling |
Laser Wavelength | 10.64 um |
Frequency of pulse | 20-100 KHz |
Marking Depth | ≤0.3 mm Depending on different materials |
Marking Speed | ≤8000 mm/s |
Marking Lines | 1-10 lines |
Minimum Line Width | 0.012 mm |
Minimum Character | 0.15 mm |
Repeatability Accuracy | ±0.003 mm |
Resolution Ratio | 0.1 mm |
Marking Content | Text, pattern, date, bar code, etc |
Operation System | Microsoft Windows XP or Windows 2000,WIN 7, WIN8, WIN 10 |
Control Software | EZCAD ENGLISH Control Software |
Graphic Format Supported | BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
Unit Power | ≤0.4 KW |
Operation Temperature | 15°C-35°C |
Relative Moisture | ≤ 90%, no fog |
Dimensions(L*W*H) | 830*540*360mm |
Power supply requirements | 220 V or 110V |
Machine Dimensions | 60*35*82cm |
Gross Weight | 48KG |
Warranty | 24 months |
The motherboard supports win10 and supports 32-bit 64-bit.
1:Fully build the platform professional fiber laser marking machine shop, please customers to patronize, do not just
look at the price. To look at the quality of the machine, use high-quality
machine parts to give customers the best price and quality service!
Provide S/N coding for our machines, machine lifetime service,
2:Machine configuration:
A;Fiber Laser brand:Lianpin/Raycus/Max
B;SINO-GALVO field mirror & galvanometer,
C;Taiwan Mingwell (MW) power supply,
D;Original Golden Orange Board (supports genuine software, supports system-wide operation)
E:Double red lights assisted focusing
F:Rotary axis (Optoinal)
3:In addition to these main accessories, we can gain an in-depth
understanding of the machine configuration of the accessories and
technical debugging of the main quality of the machine. It only provides
you with a machine that runs stably and has a low failure rate.
Machine accessories are related to the long life of the machine. In the
short term, it is impossible to compare the stability and failure rate
of the machine!
4:Never let price become the only guiding factor for the company's business marketing.
Expand your own marketing ideas and position high-quality markets.
5:Leopard and cat are similar, but different in quality. If you want a leopard or
a cat, you have the final say, I can provide it. Just the price is different!
