Supermicro AOC-S3816L-L16IT SATA SAS NVMe HBA 9500-16i 12G IT-Mode Tri-Mode

  • Free Domestic Shipping

    Orders within the US are shipped for free the next business day

  • Attractrive Prices

    Lower cost thanks to mostly pre-owned hardware

  • Sustainability

    Mostly refurbished products to reduce waste

  • Specialized in Hardware

    Expert knowledge to find custom solutions for your problems

PRODUCT DESCRIPTION

The Supermicro AOC-S3816L-L16IT is a SATA / SAS HBA that lets you increase the number of hard drives connected to your server or workstation. The host bus adapter has a PCIe x8 4.0 interface as well as 16 internal ports for SATA or SAS drives via 2 SlimSAS SFF-8654 ports. The maximum data transfer rate is 12 GBps. It is universally compatible with all known brands and uses the same chipset as the model Broadcom 9500-16i, making it functionally identical. The HBA is flashed to the latest IT mode firmware. Delivery includes full and low profile brackets for installation.

  • The Supermicro host bus adapter serves as a hardware interface for storage devices.
  • Ports: PCIe x8 4.0, 2 SlimSAS SFF-8654 Ports for up to 16 internal SATA / SAS drives
  • The maximum data transfer rate is 12 Gbps.
  • The latest IT mode firmware is installed.
  • Full and low profile brackets are included.
  • Alternatively labelled as: AOC-S3816L-L16IT, AOC-S3816L-L16IT-O, 9500-16i, 05-50077-02


Condition: Used, tested, in full working order

Included in delivery: Supermicro AOC-S3816L-L16IT, full and low profile brackets


Specifications

  • Compatible Brand For Supermicro, Universal
  • MPN AOC-S3816L-L16IT, AOC-S3816L-L16IT-O, 9500-16i, 05-50077-02
  • Standards SATA / SAS
  • Maximum Data Rate 12 Gbps
  • Compatible Product Line Universal
  • Brand Supermicro
  • Form Factor Plug-in Card
  • Type Controller Card
  • Unit Type Unit
  • Number of Ports 16 Ports
  • Item Height Full & Low Profile
  • Unit Quantity 1
  • Compatible Port PCI, PCI Express, PCI Express x8
  • RAID Levels IT-Mode
  • Internal Interfaces SAS, SATA
  • Country of Origin Taiwan
