Application：

Bigger HP Applications, perfect for all 4/6 cylinder and 2.5L-6.0L engines
for Honda K20, H22, F22 Engines
for Nissan SR20DET, RB20/25,
for Toyota 1JZ/2JZ, 7MGTE.
Also Works for Twin Turbos Applications for SBC, for LSx,
for Ford 4.6, 5.0 Engines

Note :This is universal application turbo, so modification might be required for some vehicles.

Turbo Specific：

Exhaust (Turbo Manifold) Flange: T3 Flange

Exhaust Flange: 4 Bolt

Wastegate: W/O Wastegate

Bearing Type:  Floating Bearing

Turbo Width: 240mm

Turbo Height: 230mm

Turbo length: 260mm

Maximum PSI value: 22

Horse Power: Boost Horse Power up to 600HP

Cooling Type: Water + Oil

Max HP: UP to 600hp

Oil Inlet: M10*7/16-24

Oil Outlet: M14.1 & 2*M8*1.25

Water: M14*1.5

Compressor：

Compressor Trim: 57

Inducer Diameter: 61.5 mm

Exducer Diameter: 81.5 mm

Compressor A/R: 0.7

Turbine：

Turbine Trim: 84

Inducer Diameter: 68 mm

Exducer Diameter: 62.4 mm

Turbine A/R: 0.63

Compress Inlet Size(Air intake): 4 inch (103.5mm)

Compressor Outlet Size:  2.5 inch (63.6mm)

Turbo Intercooler:

Inlet/outlet size: 2.5"
Core size: 21"x 7"x 2.5"
Full size:  27.00" (L) X 7.00" (H) X 2.50"(W)
Compress Air Flow Rate<350Cubic Feet/Min, Rated up to500 Max HP
Pressure drop:  2~5psiat35psi, 0.2~0.5psiat15psi
Material:  Aluminum alloy
Core design: Tube & Fin

Product Material:
1. Turbine housing : Iron QT450-10 shell
2. Steel Turbine Wheel: K418 alloy
3. Compressor housing: ZL104 aluminum
4. compressor wheel/blades: Cast aluminium

Condition: 100% Brand New

Warranty: 2 Year

Accessories: You will get exactly as shown in the picture above

Tips before installing:

1.Replace the air filter: if the if the air filter is not replaced may cause the compressor wheel damage.
2.Replace the engine oil: Because floating bearing and turbocharger will be damaged by impurities in the old oil.
3.After large overhaul, the engine cannot be replaced with a new turbocharger because there are too much impurities in oil after overhauling which will damage the replacement turbocharger immediately. Please run the old turbocharger for 7-10 days and then replace to new turbocharger and new engine oil.

Package Include:

1 x Turbo Charge

1 x Intercooler

1 x Pipe Kit

( Pipe Kit Include:

2x 90 Degree Aluminum Pipe 2.5"
2x Straight aluminum pipe 2.5"
2x 135 Degree Aluminum Pipe×2 2.5"
2x U Aluminum Pipe×2 2.5"
6x Straight Silicon Hose 2.5" (Blue )
2x 90 Degree Silicone Hose×2 2.5"(Blue
16x Clamps 2.5")
