Brief Introduction

MS100 SpO2 Simulator is a kind of Separated SpO2 simulator, small and light. It can perform a series of tests for the oximeter by simulation means, and gives cognizance of veracity about the oximeter.

Because the oximeter manufacturer may use different R-curves, some R-curves used abroad currently have been embedded.

Features

◆ Separated connection between simulator probe and host, operation and test are more convenient.

◆ 262K color and 320*240 TFT, adjustable brightness level.

◆ Film key-press, makes the operation more comfortable.

◆ Power with chargeable lithium battery, can display the charge information of battery.

◆ Key volume, can open or close.

Main Functions

◆ Oxygen saturation simulation;

◆ Pulse rate simulation;

◆ Patient state simulation preset;

◆ Can test the reaction time of device;

◆ Can simulate the SpO2 and pulse rate under different amplitude;

◆ Can test the performance of device under different interference source;

◆ Can select different R-curve.

Main Parameters

◆ SpO2

Measuring range: 35%~100%

Resolution:1%

Error: When SpO2 is 75%~100%, the error is the larger between ±2% and ±P(P denotes the precision of the tested oximeter); when SpO2 is 74%~50%, the error is the larger between ±2% and ±P; no define when SpO2 is less than 50%.

◆ Pulse rate

Measuring range:25bpm~250bpm

Resolution:5bpm

Error:1%±1bpm

◆ Amplitude

Measuring range:0.000%~20.000%

Resolution:1% for 1.000%~20.000%; 0.1% for 0.100%~0.900%; 0.025% for 0.000%~0.075%.

◆ Patient state

24 conditions presetting and 8 conditions as default after start. The number of condition can be adjusted by Motion level setup.

◆ Voltage

 DC 3.6V~4.2V

◆ Power Supply

 Voltage 3.7 rechargeable lithium battery × 1

◆ Battery working life

Charge and discharge no less than 500 times.

Accessaries

◆ A  MS100 user manual

◆ A  5.0V adaptor

MS400 Multiparameter Simulator is a portable device, which can provide comprehensive physiological waveform to content general test and train requirement.

It can check the monitor rapidly near the bed, also can test the quality warranty of  equipment, monitor and remote therapy equipment, At the same time,

it can be used as the training of distinguishing from arrhythmia waveforms to the nurses.

3.5-inch color TFT touch-screen, 320*240 pixels, friendly operation interface.

Display the output waveforms synchronously, which is convenient for user to compare with the test equipment.

It integrates the functions of SD socket interface, user can output the custom waveform by this device.

Built-in templates list to provide the waveform that is expressed by each preset sequence number,which is convenient for searching.

Two operation interfaces:Chinese and English.

Operate with keystroke and touch-screen expediently and rapidly.

Built-in 3.7V/4000mAh(Rechargeable alkaline battery).

Optical external power: AC 220V, 50Hz or AC 120V, 60Hz

Arrhythmia

Conventional: All leads have the same voltage with the II-lead as the reference

Amplitude: 0.5,1.0,1.5 and 2.0mV

The accuracy of Amplitude: ±2%

 Rate: 15,20,25,30,40,60,80,100,120,140,160,180,200,220,240,260,280,300,320,340 and 350 BPM

 artifacts: 50 or 60 Hz, muscle, baseline drift and breathing

The elevation of the ST segment: -0.8 mV to +0.8 mV, the step is 0.1 mV

The default: 80 BPM,1mV

Arrhythmia

Atrial: Atrial Fib(coarse), Atrial fib(fine), Atrial Flutter, Sinus Arrhythmia, Missed Beat, Atrial

Tachycardia, Nodal Rhythm, Supraventricular Tachycardia

Ventricular: Vent Fib (coarse), Vent Fib (fine), Premature Ventricular Contraction (PVC) 6/min,

PVCs 12/min, PVCs 24/min, Freqent Multifocal, Bigeminy, Trigeminy, Paired PVCs, Run 5

PVCs, Run 11 PVCs, Vent Tachycardia, Asystole

Premature Beat: Atrial Premature Atrial Contraction (PAC), Nodal PNC, Left Ventricular Focus

PVC1, Early Left Ventricular Focus PVC1, Right Ventricular Focus PVC1, Early Right

Ventricular Focus PVC1, R on T Left Ventricular Focus, R on T Right Ventricular Focus, Multifocal PVC

Conduction Defects: First Degree Heart Block, Second Degree Heart Block, Third Degree Heart Block, Right Bundle Branch Block, Left Bundle Branch Block

Performance Testing

 amplitude0.5,1.0,1.5 and 2.0mV

The accuracy of Amplitude: ±2%

Pulse: 30 and 60 BPM, the width of pulse wave is 60 ms

Square: 0.125 and 2.0 Hz

Triangle: 2.0 and 2.5 Hz

Sine: .0.5, 5, 10, 40, 50, 60 and 100 Hz

Rate:15, 20, 25, 30, 40, 60, 80, 100, 120, 140, 160, 180, 200, 220, 240, 260, 280, 300, 320, 340 and 350 BPM

The accuracy of  Rate: ±1%

Respiration

Respiration Rate: 0 (Apnea), 15, 20, 30, 40, 60, 80, 100, 120 and 150 R/MIIN

Respiration Impedance: 0.2, 0.5, 1.0 and 3.0 Ω

Baseline Impedance:500,1000,1500 and 2000

Apnea: 12 s, 22 s, 32 s

simulator with adjustable heart rate/12-lead output

33 kinds of Arrhythmia waveforms

Pacemaker

Two IBP channels

Variety of respiratory impedance,apnea pauses (0 BrPM) of 12, 22 and 32 seconds.

Standard  calibration

Export square,triangle and sine with adjustable frequencyIBP

The default: 00/00mmHg

Dynamic IBP

Channel 1: Artery 120/80mmHg

Radial 120/80mmHg

Left Ventricle 120/00mmHg

Right Ventricle 25/00mmHg

Channel 2: Artery 120/80mmHg

Radial 120/80mmHg

Left Ventricle 120/00mmHg

Right Atrium 15/10mmHg

Right Ventricle 25/00mmHg

Pulmonary Artery 25/10mmHg

Left Atrium 14/4mmHg

Static-Pressure Levels

Channel 1: 0, 80, 160, 240, 320 and 400mmHg

Channel 2: 0, 50, 100, 150, 200 and 250mmHg
