Items Performance & Parameter Meter Principle Transit time ultrasonic flowmeter Accuracy ± 1% Display 4×16 character LCD with backlight, support the language of Chinese, English and Italian Signal Output 1 way OCT pulse output(Pulse width 6~1000ms, the default value is 200ms) Data Interface Insulate RS232 serial interface, upgrade the flowmeter software by computer Pipe Installation Condition Pipe Material Steel, Stainless steel, Cast iron, Copper, Cement pipe, PVC, Aluminum, Glass steel product, liner is allowed. Pipe Diameter 15~6000mm Straight Pipe Transducer installation should be satisfied: upstream 10D, downstream 5D, 30D from the pump. Measuring Medium Type of Liquid Single liquid can transmit sound wave, such as water, sewage, oil, chemicals, plant effluent, beverage, ultra-pure liquids, etc. Temperature -30~160°c Turbidity Less than 10000ppm and little bubble Flowrate 0 ~ ±7m/s Working Environment Temperature main unit: -20~60°c; Transducer: -30~160°c Humidity main unit: 85%RH; Transducer protection level: IP67 Power Supply 3 built-in Ni-MH batteries 1.2V(for over 12 hours of operation). Achieve to continuous measurement by connecting AC 90V - 260V adapter. Power Consumption 1.5W Housing Material Inflaming retarding ABS Main unit Weight 390g
