Dental Oral Camera Wireless WiFi Oral HD Oral Intraoral Endoscope Camera EC-3

1.Model:EC-3

2.Size:210*25*20mm

3.Image pixel：300W

4.Frame Rate：20fps

5.LED：8 PCS

6.Operate Time:About 150min

【Method 1】:Open the mobile app store, Search “EndoCamera”, and click Download and Install. (Huawei Application Market/ Xiaomi App Store /OPPO App Store VVO App Store /iPhone App Store/, Tencent App treasure /360 mobile phone assistant can be searched and Download.)

【Method 2】:Scan the QR code, select "EndoCamera.apk" to download and install the APP.

Note: When installing App “Endocamera”, please allow all the authority request it need.

2.When using by mobile phone, manually connect to a WiFi hotspot in WLAN 1. Settings. Open the downloaded APP, enter the interface in Figure 1, and click "EC-3" to connet. Enter the interface shown in Figure 2, manually connect the WIFI "EC3_XXXXX" and return Then enter the device interface as shown in Figure 3. Click the "Start" button to start showing image. Click the "Close" button to power off the device and exit the APP.

3. For computer using, it needs to manually connect to the WiFi in WLAN Settings. Type in the website on web browser ” vvdental.com.cn”, Click the "Data Download" column to download EndoCamera_install.exe to install, After the installation, open the PC client software, manually connect the hot spot "EC-3-XXXX", and click the" Start playing " button in the page to showing image.
