Leister TAPEMAT Automatic Welder, 400V 10000W, 50mm - 129.757
DETAILS Quick tape welding
The TAPEMAT automatic welder enables quick tape welding on truck tarpaulins and industrial fabrics with PVC straps. Thanks to a process-optimized nozzle and excellent heating output, with a low-maintenance, brushless blower motor, high welding speeds are possible. With welding speeds up to 20 m/min (66 ft/min), the TAPEMAT is one of the quickest tape automatic welders on the market with an extremely high quality finish. Speed and temperature welding parameters can be adjusted perfectly for different materials. This means that large projects are no problem.
Technical Data
Article: 129.757
Voltage: 400 V
Frequency: 50/60 Hz
Power: 10000 W
Speed: 4 - 20 m/min / 13.12 - 65.62 ft/min
Temperature: 100 - 650 °C / 212 - 1202 °F
Air Volume Adjustable: No
Welding Nozzle / Seam Width: 50 mm / 1.96 in
LQS: No
Brushless Blower Motor: Yes
Length: 555 mm / 21.85 in
Width: 435 mm / 17.12 in
Height: 370 mm / 14.56 in
Weight: 35 kg / 77.16 lb
Plug: CEE red, 5 poles, 16A
Power Cable Length: 1.1 m / 3.6 ft
Approvals: CB Certification; CE; S+; UKCA
Protection Class: I
Country Of Origin: Switzerland
HIGHLIGHTS Quick tape welding
1. High welding speed up to 20 m/min (66 ft/min)
2. Ideal for truck tarpaulins and industrial curtains
3. Low-maintenance, brushless motor
4. Integrated tape delivery system
5. Process-optimized nozzle
6. Intuitive operation
7. Easy to use
APPLICATIONS Virtually unlimited
Protective cover welding
Advertising banner welding
Tent tarpaulin welding
Awning and wind blocker welding
Flexible tank welding
Truck tarpaulin welding
