Name: V-shaped vise
Model: 3 inches
Total length of clamp body: 175MM
Clamp body height: 135MM
Jaw width: 80MM
Clamping diameter: 7-50MM
Positioning key width: 14MM
Total width of clamp body: 156MM
Installation slot distance: 135MM
Net weight: 10.4KG
Gross weight: 10.8KG

Model: 4 inches
Total length of clamp body: 235MM
Clamp body height: 185MM
Jaw width: 100MM
Clamping diameter: 10-80MM
Positioning key width: 14MM
Total width of clamp body: 168MM
Installation slot distance: 150MM
Net weight: 19.6KG
Gross weight: 20.1KG

Model: 8 inches
Total length of clamp body: 295MM
Clamp body height: 255MM
Jaw width: 200MM
Clamping diameter: 25-105MM
Positioning key width: 18MM
Total width of clamp body: 275MM
Installation slot distance: 250MM
Net weight: 52.6KG
Gross weight: 57.4KG
