M10x35mm Cap Head Allen Key Screw Socket Screw
Steel Grade 12.9
DIN 912
| Technical Specifications | |
|---|---|
| Sizes | M10x35mm |
| Thread Diameter (D) | 10 mm |
| Length(L) | 35 mm |
| Fully Threaded | Yes |
| Thread Length [Min] (TL) | 35 mm |
| Pitch(P) | 1.5 mm |
| Allen Key Size (S) | 8 mm |
| Head Thickness (T) | 10 mm |
| Head Diameter (HD) | 16 mm |
| Socket Depth (SD) | 5 mm |
| Material | Steel |
| Grade | Grade 12.9 |
| Standard | DIN 912 |
