Notice:

Please confirm that your car's displacement is between 1.5-2.5L .

Please check the size before purchasing and make sure that your car has enough space to install this turbo.

Fit for:

for 1.5L to 2.5L any 4/6 cylinder engine

Specification:

Turbine:
Turbine Intake Flange: T3 T4 4 bolt Flange Patterns
Turbine Exhaust Flange: Standard T3 5 bolt flange pattern
Turbine Trim: 74.2
Turbine A/R: 0.63
Turbine Inducer: 64.8mm
Turbine Exducer: 55.8mm
Turbine exhaust inlet: 44.5mm/81mm
Compressor:
Compressor Trim: 48.1
Compressor A/R: 0.5
Compressor Inducer: 52.7mm
Compressor Exducer: 76mm
Compressor outlet: 45mm(inside diameter), 53mm(outer diameter)
Compressor inlet: 468 mm(inside diameter), 72mm(outer diameter)

Oil Inlet: M12*1.25
Oil Outlet:2*M8*1.25

Cooling Type: Oil Cooling
Bearing Type: Journal Bearing/Floating Bearing
Thrust bearing: 270 degrees
Horse Power: Up to 400 hp
Wastegate: Without Wastegate
Actuator Type: W/O Actuator
Turbo Type: Individual
Universal Fitment: Yes
Finish: Matte
Condition: 100% Brand New
Accessories: You will get exactly as shown as picture above
Package Size: 27x 25x 24 cm
Package Weight: 7250g

Oil Line information：

 *OIL RETURN LINE: Length: 550mm || Inner Diameter: 21mm

  *OIL FEED LINE: Length: 1000mm || Inner Diameter: 14mm

*Fitment：T3, T3/T4, T4, T04, GT32, GT40, GT42, GT4088R, GT4049R, GT42R/RS, GT4294R, GT4202R, T61, T66, T70（fit for most turbos）

Intercooler Information：

 *Inlet / outlet size :    2.5"

 *Core size :  21''x 7''x 2.25''/550x175x64mm

  *Full size:  27.00" (L) X 7.00" (H) X 2.50"(W)

 *Compress Air Flow Rate<350Cubic Feet/Min, Rated up to500 Max HP

*Pressure drop:  2~5psiat35psi, 0.2~0.5psiat15psi

*Material:  Aluminum alloy

 *Core design:   Tube & Fin

 *Applaction:  Universal

Intercooler Piping Pipe Kit Information：

  *Application：Universal fits all Turbo Projects

*Description：

 Pipe Thickness: 1.8mm

  Pipe length: 18''

Package Included:You will get exactly as shown in the picture above

Condition: 100% Brand New

NOTE:

* Does NOT have a internal wastegate so you must have a external wastegate on your manifold.
* Replace, repair or reconnect air cleaner element per manufacturer's manual to avoid compressor wheel damage.
* Make sure the oil drain line is lower than the turbo itself.
* Ensure exhaust outlet are well sealed by welding
* The degree of modification of the universal turbo depends on your individual vehicle.
* Professional installation is highly recommended.
* This Turbo is not vehicle specific. Please check the specifications and verify compatibility prior to placing your order.
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
