Autel MX-Sensor 2 In 1 (315 + 433MHz)
As a programmable universal sensor featuring in Clamp-in and Snap-in options which are both smart and efficient specially built for sensor replacement with maximum application coverage, ease of use, OE-level fit, performance and reliability, will help users economize the cost of diagnostic work and raise the repair efficiency greatly.
【2 IN 1 with OE-Level Design, Solid and Functional】
This tire pressure monitoring sensor (for TPMS) has been manufactured to combine both 315 MHz and 433 MHz applications in one sensor to greatly simplify users’ inventory management and lower the investment as well as sales loss. And it is built to perform like OE sensors in terms of signal, durability and functionality as follows:
1.The unique Autel MX-Sensor patented press release valve design allows rubber and metal sensor valves to freely interchange by hand, without requiring a tool for sensor head fitting.
2.It is equipped with an automotive-grade battery to meet severe weather conditions with long service life for over 5 years.
3.Its high-precision air valve is able to prevent air leakage. The high-quality housing can withstand cold, hot and resistance corrosion.
4.The replaceable aluminum valve stem is anodized for corrosion resistance.
5.The device can be assembled real quick to minimize the installation time.
6.12G weight makes the sensor significantly lighter than most sensors in the market.
7. The replaceable aluminum valve stem is anodized for corrosion resistance.
【Comprehensive Vehicle Coverage】
Sensor updates during installation from the Autel wireless programming tool which gives the Autel Sensor 2 in 1 a long ability to cover over 98% of all OE sensors on the market, to support up 90% of North American, European and Asian brands
【Specification】
Battery Life: ≥5 years
Operating Temperature: -40°C to +125°C
Storage Temperature: -40°C to +150°C
Operating Humidity: 90%
Operating Frequency: 433 MHz/315MHz
Pressure Monitoring Range: 100 to 900 kPa
Pressure Reading Accuracy : ±10 kPa
Temperature Reading Range : -40°C to +125°C
Temperature Reading Accuracy: ±5°C
G Sensor Reading Accuracy : ±15%
Transmission Power : 5-8 dBm
Battery : 3.0 V
Dimensions (W x H x D) 55.1 mm x 29.4 mm x 21.8 mm (Clamp-in Sensor)
Weight (Without Valve) 18.5 g (Clamp-in Sensor)
【Package】
1 * Sensors
