Kyosho 32894 MINI-Z MR-04EVO2 W-MM 5600KV Chassis Set

Kyosho 32894 MINI-Z MR-04EVO2 W-MM 5600KV Chassis Set

Product Description:

Build a high-performance MINI-Z racer with the Kyosho 32894 MR-04EVO2 W-MM Chassis Set. Designed for experienced MINI-Z drivers, this factory-assembled chassis features a KYOSHO SPEED HOUSE XSPEED 56 5600KV sensored brushless motor and advanced electronics for precise, responsive control.

The MR-04EVO2 retains the proven MR-03 layout while introducing a redesigned front suspension, lower battery position and improved steering geometry. Its Front Suspension Arm 2.0 increases rigidity to provide more precise handling and greater stability on the track.

A factory-installed ball differential helps balance the speed of the rear wheels while cornering and provides controlled slip under heavy load for improved traction. The chassis also supports narrow and wide front tread settings, allowing it to be adjusted for compatibility with different MINI-Z body configurations.

The updated EVO2 electronics support high-speed communication with compatible receiver units and allow motor RPM settings to be adjusted through the I.C.S. Setting Manager.

Please note that this is a chassis set only. A compatible transmitter, receiver unit, Auto Scale body, wheels, tires and batteries are required separately.
