Notifier FMM-1 Intelligent Monitor Module

FOLLOW US HAVE A QUESTION?

PRODUCT DESCRIPTION

The Notifier FMM-1 is an intelligent addressable monitor module for Notifier two-wire SLC systems that supervises a circuit of dry-contact input devices. It supports Style B (Class B) or Style D (Class A) wiring for normally open fire alarm and supervisory contacts, reports open/normal/short status to the panel, and can be used to replace MMX-1 modules in existing systems. Key Specifications: Type: Intelligent addressable monitor module Core Function(s): Monitors and supervises a dry-contact IDC and reports OPEN/NORMAL/SHORT status to the panel Loop/Protocol: Notifier SLC; FlashScan (01-159) and CLIP (01-99) addressing via rotary switches Power: 15 to 32 VDC (SLC); 5.0 mA max (LED on); 375 uA average (LED flashing) Indicators/UI: Panel-controlled LED (flashes green in normal operation as a programmable option; latches steady red in alarm) Circuit Style: Style B (Class B) or Style D (Class A) dry-contact IDC; 47K end-of-line resistor for Style B Wiring Limits: 47K EOL; maximum IDC wiring resistance 1,500 ohms; maximum IDC voltage 11 V Mounting: Mounts to a 4-inch square, 2.125-inch deep electrical box Compatible Accessories: SMB500 - Optional surface-mount backbox CB500 - Control module barrier for separating power-limited and non-power-limited wiring in the same box System Compatibility: Works with Notifier intelligent fire alarm control panels that support FlashScan or CLIP operation on the SLC loop.
The Notifier FMM-1 is an intelligent addressable monitor module for Notifier two-wire SLC systems that supervises a circuit of dry-contact input devices. It supports Style B (Class B) or Style D (Class A) wiring for normally open fire alarm and supervisory contacts, reports open/normal/short status to the panel, and can be used to replace MMX-1 modules in existing systems. Key Specifications: Type: Intelligent addressable monitor module Core Function(s): Monitors and supervises a dry-contact IDC and reports OPEN/NORMAL/SHORT status to the panel Loop/Protocol: Notifier SLC; FlashScan (01-159) and CLIP (01-99) addressing via rotary switches Power: 15 to 32 VDC (SLC); 5.0 mA max (LED on); 375 uA average (LED flashing) Indicators/UI: Panel-controlled LED (flashes green in normal operation as a programmable option; latches steady red in alarm) Circuit Style: Style B (Class B) or Style D (Class A) dry-contact IDC; 47K end-of-line resistor for Style B Wiring Limits: 47K EOL; maximum IDC wiring resistance 1,500 ohms; maximum IDC voltage 11 V Mounting: Mounts to a 4-inch square, 2.125-inch deep electrical box Compatible Accessories: SMB500 - Optional surface-mount backbox CB500 - Control module barrier for separating power-limited and non-power-limited wiring in the same box System Compatibility: Works with Notifier intelligent fire alarm control panels that support FlashScan or CLIP operation on the SLC loop.
