The PAC IGN-3 Phantom Ignition Module is designed to detect when a vehicle’s engine is running and provide a switched accessory power output for aftermarket electronics. It is especially useful for modern vehicles equipped with CAN-Bus electrical systems and automatic start-stop technology, where traditional ignition wires may not behave consistently. The module simplifies installation of accessories such as dash cameras, amplifiers, or other electronics that require reliable accessory power. With its power-off delay feature, the IGN-3 keeps accessories powered even during temporary engine shutdowns, such as when a vehicle stops at a red light. Users can choose between a 10-second delay for typical stop-start vehicles or an extended 140-second delay, ensuring that connected devices remain powered during short engine interruptions. The compact design and simple three-wire installation make it an efficient solution for modern vehicle accessory installations.

• The PAC Latching Phantom Ignition Module for Start/Stop Vehicles is designed to detect when the engine is running and provide a switched accessory power output wire for aftermarket electronics. It is an effective solution for modern CAN-Bus vehicles where traditional accessory power sources may be inconsistent or difficult to access, making installation cleaner and more reliable.
• This module is especially useful for vehicles equipped with stop-start technology, as it helps keep connected accessories powered during temporary engine shut-downs such as red lights or alternator disengagement while driving. With selectable power-off-delay settings of 10 seconds or 140 seconds, up to 2 amps of output, and a simple 3-wire installation, it offers flexibility and dependable performance for a wide range of aftermarket applications.

• Key Features
• Engine Running Detection: Detects when the engine is running and provides a switched accessory power output wire for triggering compatible aftermarket accessories.
• Selectable Power-Off Delay: Offers two delay settings, including 10 seconds for typical stop-start operation and 140 seconds for extended accessory power retention.
• Designed for CAN-Bus Vehicles: Helps simplify aftermarket accessory installation in modern CAN-Bus vehicles where standard ignition signals may be limited.
• Supports Stop-Start Systems: Keeps connected electronics from shutting down during engine stop-start events, such as idling at red lights.
• Simple 3-Wire Installation: Features an easy installation design that helps reduce complexity during accessory integration.
• Up to 2 Amps Output: Provides up to 2 amps of output for powering compatible aftermarket electronic accessories.

• Item Details
• Product Type: Latching Phantom Ignition Module
• Brand: PAC
• Model: IGN-3
• Application: Start/Stop Vehicles
• Vehicle System Compatibility: CAN-Bus Vehicles
• Main Function: Detects engine running status and provides switched accessory power output
• Power-Off Delay Options: 10 Seconds or 140 Seconds
• Installation Type: 3-Wire Installation
• Maximum Output: Up to 2 Amps
• Ideal Use: Triggering aftermarket electronic accessories
