• Ship from NSW,Australia,2-6 working days delivery with tracking.

•


• Current : 100A,80A,60A,50A

• Voltage : 12V/24V/36V/48VDC Auto,max PV input voltage ; 150V or 200V.

• Tracer-AN series, Epever MPPT Solar Charge Controller

• Negative ground

•


• Overview:

• Tracer-AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer-AN products can rapidly track the maximum power point(MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment.

•


• With the adaptive three-stage charging mode based on digital control circuit, Tracer-AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility and generator auto-control relay output make it easy to connect other equipment. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. The isolated RS485 interface with standard MODBUS communication protocol makes it easy for customer to expand the application, greatly meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring, etc.

About Tracer-AN series

• Negative Ground 150V/200V PV Input, Compatible with 12/24/36/48V Batteries (Lead Acid) Charging. Lithium Battery :LiFePO4/ Li(NiCoMn)O2,Only Solar Panel and Battery Connector Available
• Dual RS485 Port (RJ45 Connector), it can be paralleled up to 8 units together linked by 8pin ethernet cable to make the data monitoring easy and accurate.
• Battery Type Compatibility, Lead Acid: Sealed, Gel, Flooded and User define, Lithium Battery: LiFePO4/ Li(NiCoMn)O2 / User, Battery temperature compensation will make the charging progress efficiently.




•


• Product Feature

• Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5%
• Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98%
• Advanced MPPT control algorithm will minimize the MPP loss rate and loss time
• The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP
• Charging power and current limitation
• High-temperature charging power derating function

• Standard Modbus communication protocol with RS485 interface

• Negative Grounding Design
• 150V/200V PV input allows more panels connected in series

• Support up to 8 units paralleled

Electrical Parameters:

Item	Tracer5415AN	Tracer6415AN	Tracer8415AN	Tracer10415AN	Tracer5420AN	Tracer6420AN	Tracer8420AN	Tracer10420AN
Nominal System Voltage	12/24/36/48VDC or Auto
Battery Input Voltage Range	8V～68V
Battery Type	Sealed/Gel/Flooded/User
Rated charge current	50A	60A	80A	100A	50A	60A	80A	100A
Rated charge Power	625W/12V	750W/12V	1000W/12V	1250W/12V	625W/12V	750W/12V	1000W/12V	1250W/12V
	1250W/24V	1500W/24V	2000W/24V	2500W/24V	1250W/24V	1500W/24V	2000W/24V	2500W/24V
	1875W/36V	2250W/36V	3000W/36V	3750W/36V	1875W/36V	2250W/36V	3000W/36V	3750W/36V
	2500W/48V	3000W/48V	4000W/48V	5000W/48V	2500W/48V	3000W/48V	4000W/48V	5000W/48V
Max. PV open	150V (At minimum operating environment temperature)				200V (At minimum operating environment temperature)
circuit voltage	138V (At 25℃ environment temperature)				180V (At 25℃ environment temperature)
MPP Voltage Range	(Battery voltage +2V)～108V①				(Battery voltage +2V)～144V①
Tracking efficiency	≥98.0%
Conversion efficiency	≤99.5%
Temperature compensate coefficient	－3mV/℃/2V (Default)
Self-consumption	98mA/12V;60mA/24V;50mA/36V;46mA/48V
Grounding	Common negative
RS485 interface	RS485(RJ45)
LCD backlight time	60S (Default)





① The Max. PV open circuit voltage must never exceed 138V or 180V at 25℃ environment temperature.

•
