mICRO INVERTER 600wATT MPPT 230V WIFI MONITOR - GRID TIED - ENA -CERTIFIED

15 YEAR WARRANTY - Top of the range components.

Micro inverters are simple and very easy to use. There is no need for programming; the installer does not have to set up any parameters. It is literally plug-and-play with two direct power connections: the solar panels are connected to the MC4 connectors, and the AC output is plugged straight into the nearest 230V outlet (socket).

This means you can now produce green energy from a single panel. If you run out of space, there is still a good chance to generate electricity from 1, 2, or 3 panels.

Benefits and Technological Advances

• Roofs with multiple orientations (south, southwest, southeast, east, etc.)
• Get the maximum energy yield from each mounting angle and roof orientation.
• The performance of each panel does not influence the other panels.
• If a panel is damaged or in shadow, it will not impact the rest of the system.
• Micro inverters are made to match the lifespan of the panels (25 years+).
• An advanced monitoring system allows you to check the performance of every panel.
• More energy production (10-20%) compared to string inverters.
• Faster payback.
• 10 years warranty.

Recommended Input Power

• (400~600W) × 1, 60~75 full/120~150 half-cut cells
• (280~330W) × 2 parallel, 72~75 full/144~150 cells
• Output Power: 520VA (Vac 230, Vmp 34)
• Rated Frequency: 50Hz/60Hz (46.5-62)Hz
• Peak Efficiency: 96.5%
• Up to 12 inverters on a single line (cable), in a daisy chain.

(HS CODE: 8504403090)

Notice:

This inverter requires a grid connection; it does not work off-grid or in parallel with off-grid inverters.
