The hammer crusher can crush larger materials into smaller sizes at once, and the crushing ratio is usually as high as 10-25 or even higher, thereby reducing the crushing process and improving production efficiency. Its working principle is based on the impact crushing of materials by high-speed rotating hammers, which can continuously crush materials. Therefore, it has high production capacity and can meet the needs of large-scale production. The materials in the stamping chamber are subject to many impacts and collisions of the hammer, and can be crushed into uniform particle size. The product size is cubic, with low content of needle shaped particles, which is conducive to improving the quality of secondary products.
Hammer crusher specification
|
Model |
Max feeding size (mm) |
Discharging size (mm) |
Capacity (t/h) |
Power (kw) |
Weight (t) |
|
PC200 * 300 |
125*250 |
0-8 |
1-3 |
5.5 |
0.2 |
|
PC240 * 450 |
240*450 |
0-8 |
5-7 |
7.5 |
0.4 |
|
PC320 * 510 |
320*510 |
0-8 |
7-10 |
15 |
0.55 |
|
PC400 * 600 |
400*600 |
0-8 |
10-15 |
22 |
0.8 |
|
PC600 * 600 |
600*600 |
0-15 |
20-30 |
30 |
1 |
|
PC600 * 800 |
600*800 |
0-15 |
30-50 |
55 |
1.8 |
|
PC800 * 1000 |
800 |
0-15 |
50-80 |
75 |
2.8 |
|
PC1000 * 1000 |
1000 |
0-15 |
80-100 |
110 |
4.5 |
