About this article

• Portable ECG Machine：Light in weight of 250g, easy to carry.

• Automatic Interpretation：Advisory rhythm analysis based on authorized databases.

• WiFi Transmission：Share patient data via email, USB drive or WiFi network.

• Adults & Pediatrics：Support resting ECG tests and analyses for adults & children.

• Easy Patient Management：ECG reports in ECG, PDF, BMP, DAT; easily import to hospital management system.

• All-Day Long Battery Life：Continuously work for 24 hours after fully charged. Ideal for long-hour shifts and patient monitoring.

• 10,000+ Files Stored：Store more than 10,000 ECG cases, 10 times larger than traditional ECG machines.

• 8 Language Settings：English, Español, Português, Français, русский язык, Italiano, Deutsch, Chinese

• Physical Details:
  Device Dimensions：134 mm × 74 mm × 17 mm ( 5.28" × 2.91" × 0.67")
  Weight：250g (unit & battery in total)
  Display：4.46 inches color LCD touchscreen
  Screen Resolution：480 × 854 pixels
• Tech Specifications:
  Leads：6-lead / 12-lead synchronous acquisition and analysis
  Heart Rate Calculation：Peak-peak detection
  Wireless Data Transfer：Email, USB disk, WiFi (FTP)
  Compatible Network Printers：200+ Models including HP, Brother, Epson, Canon
  ECG Acquisition Time：10s
  Rhythm Time：10-180s
  Heart Rate Range：30 bpm~300 bpm
  Accuracy：±1bpm
  ECG Input Signal Range：≤±5mVp-p
  Minimum Detectable Signal：20μVp-p
  Frequency Response：0.05Hz～150Hz, 10Hz
  Sensitivity：2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV Accuracy: ±5%
  A/D Conversion：24 bits
  Sampling Rate：2000 samples/sec
  Common Mode Rejection Ratio (CMRR)：≥100dB (AC filter on)
  Time Constant：≥3.2s
  EMG Filter：25Hz, 35Hz, 45Hz, Off
  ADS Filter：0.67Hz
  Lowpass Filter：75Hz, 100Hz, 150Hz, Off
  AC Filter：50Hz, 60Hz, Off
  Speed：5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s Accuracy: ±3%
  Noise：≤30μVp-p
  Record Format：For 6-lead: 6×1, 3×2；For 12-lead: 12x1, 6x2, 6x2+1R, 3x4, 3x4+1R, 3x4+3R
• Battery:
  Rechargeable：Rechargeable Lithium Battery
  Rated Voltage：3.8V
  Rated Capacity：6000mAh
  Battery Life：24-hour continuous operating
  Charging Time：8 hours

• 【What does the ECG report include?】
  A report usually includes waveform area, patient information area, measurement parameter area, diagnosis result area. You can also select to print the average template (only available for 6-lead) and measurement matrix information.
  Measurement parameters include:
  HR (Heart rate) (bpm), P Duration (ms), PR Interval (ms), QRS Duration (ms), QT/QTc Duration (ms), P/QRS/T Axis (°), RV5/SV1 Amplitude (mV), RV5+SV1 Amplitude (mV), RV6/SV2 Amplitude (mV)
  Diagnosis result:
  Shows the auto diagnosis result.
  Average template:
  Gives the average value of 10s acquired ECG signal of each lead.
  Measurement matrix:
  Gives 14 measurements of each lead, including:
  P amplitude (mV), Q amplitude (mV), R amplitude (mV), S amplitude (mV), T amplitude (mV), ST1 amplitude (mV), STJ amplitude (mV), ST20 amplitude (mV), ST40 amplitude (mV), ST60 amplitude (mV), ST80 amplitude (mV), Q duration (ms), R duration (ms), S duration (ms)

• 【What are the benefits of Automatic ECG Interpretation by Glasgow Algorithm?】
  Helps in QTc measurements facilitating assessment of cardiac risk.
  Highly effective in interpreting STEMI (ST Segment Elevation Myocardial Infarction).
  Can utilize V4R for neonates and children.
  Offers short diagnostic reports for hospitals and detailed reports for primary care settings.
  Critical values included in diagnostic reporting template.
  Pocket ECG machine combines complete data with sophisticated proprietary algorithms for comprehensive statistical analysis.
