Maximum Real Time Sampling Rate: 1Msps

Precision: 12Bit

Sampling Buffer Depth: 1024 bytes

Number of Channel: 1

Analog Band Width: 0~200KHz

Vertical Sensitivity: 5mV/Div~20V/Div (progressive by 1-2-5)

Trigger Position: 1/2 of buffer size fixed

Sensitivity Error: < 5%

Input Impedance: 1M Omega

Power Supply: 9V DC

Supply Current: 120mA

Maximum Input Voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe)

Coupling Methods: DC/AC/GND

Horizontal Time Base Range: 10 s/Div~50s/Div (progressive by 1-2-5)
