Product Description



Features:

1. 10.1 inch IPS screen with 1280*800 resolution

2. RK3566 quad core , RAM 2GB+ ROM 32G, Android 11

3. Access to all available Android applications , Supported rooted Android system

4. RJ45 Ethernet port for POE function

5. RS485, Type C USB port

6. Flush in wall install

7 .CNC Metal Slim case





Specification:





System	CPU	RK3566 Quad-Core A55,up to 1.8GHz
	Ram	2Gb
	Rom	16Gb
	System	Android 11 with google play store
Touch panel	Display size	10 inch
	Resolution	1280*800
	Touch Panel	10 points capactive IPS touch panel, Size:256.49*174.49mm
	Brightness	500Nits
	Active area	16:9 / Display area : 218*135mm
Network	WIFI	2.4G WIFI (5G wifi option)
	Blue--tooth	BT 4.0
	Ethernet	10M/100M
Material	Metal case	Metal case  (Size:253*9.58 mm)
Interface	RJ45	Ethernet interface input (RJ-45 cable) ,Support POE
	DC	12V INPUT
	Type C	Type C*1
	Set	Reset*1
	Restart	Restart *1
	Mic	Mic*1
	Camera	Camera option
	RS485	Yes
Braket	Metal  bracket	Metal  bracket
Media plays	Speaker	2pcs Speaker *2W
	Video	MOV 1080P / AVI / WMV / RM / RMVB / 3GP / MKV / MP4 / ASF/ VOB
	Audio	MP3 / WMA / WAV / AAC / FLAC / OGG
	Entertainment	Video / Movie / Music / FM online
Others	Battery	NO
	Mount	In wall
	Color	Black/Silver color
	Language	Multi English
