Parameter
Marking speed: 2000mm/s
Positioning speed: 7000mm/s
Input voltage: about 15VDC
Rated current: 2A
Input spot diameter (mm): 10
Lens reflection wavelength: 1064nm / 355nm / 532nm / 10.64um
Maximum Scanning Angle: about 12.5
Small signal step response time (ms): 0.35
Moment of inertia g*cm2: about 0.25
Maximum average operating current: 0.5
Peak current: 10
Linearity:more than 99.9%
Repeatability: less than 8
Long-term continuous work drift, more than 8 hours: less 0.5
Operating ambient temperature: 15-35 dgree
