4-20ma stainless steel pressure sensor Integrated differential pressure transmitter

The HDP702 series integrated differential pressure transmitter is assembled with an OEM silicon piezoresistive differential pressure oil-filled core. The outer casing is made of stainless steel and has strong corrosion resistance. The two pressure ports are threaded and can be mounted directly on the measuring pipe or connected via a pressure pipe.

The HDP6100 series is available in standard voltage and current output, and can be easily installed and use'd. It is widely use'd in process control, aerospace, aerospace, automotive, medical equipment, HVAC, etc. for differential pressure, liquid level, flow measurement and control, etc.
