WS3032 anemometer is a kind of measuring instrument which uses the time difference of ultrasonic wave in the air to measure the wind speed and direction. WS3032 uses a low power chip inside, and the power consumption of the whole instrument is only 0.2W, which is especially suitable for the solar or battery powered environment with high power consumption requirements. As a result of adopting new technology and new process, the structure is more compact and compact, the cost is greatly reduced compared with the original WS3032 series anemometer, and the shell has two kinds of metal casting aluminum and ABS, which are convenient for users to use in different environments It is mainly used in family meteorological station, farmland meteorological detection, tower crane wind speed monitoring, etc.
|
Measure Range
|
Wind Speed :0-40m/s; Wind Direction :0-359°
|
|
Accuracy
|
Wind Speed :±3%; Wind Direction : ±3°
|
|
Resolution
|
Wind Speed :0.1m/s; Wind Direction : 1°
|
|
Power supply
|
5-30VDC
|
|
Protection Class
|
IP65
|
|
Operating Environment
|
-30℃ to +60℃; 0-100%RH
|
|
Output options
|
RS232,RS485,SDI-12,4-20ma
|
|
Dimension/Weight
|
Φ84×120mm ,ABS:0.38kg,Aluminum alloy:0.78kg
|
|
Material of body
|
ABS engineering plastic/Aluminum alloy
|
|
Consumption
|
0.2W(wind ,temperature,humidity,air pressure )+1.5W(rainfall)
|
