Products Description
|
Phase
|
Single phase
|
Three phase
|
|
Input/Output voltage
|
110~250Va.c.
|
110~450Va.c.
|
|
Frequency
|
50Hz/60Hz
|
50Hz/60Hz
|
|
Max. current
|
16A/32A
|
16A/32A
|
|
EV connector
|
Type 1 & Type 2
|
Type 2
|
|
RCD
|
Type A
|
Type A+6mA d.c.
|
|
IP degree
|
IP65
|
IP65
|
|
Operating temperature
|
-25°C~+50°C
|
-25°C~+50°C
|
|
Relative humidity
|
5%RH~95%RH
|
5%RH~95%RH
|
|
Altitude
|
<2000m
|
<2000m
|
|
Static Power
|
<2W
|
<2W
|
|
Dimension
|
278mm(L)x81mm(D)
|
278mm(L)x81mm(D)
|
|
Standards
|
IEC/EN 62752
|
IEC/EN 62752
|
