Full Hd media player digital signage box for advertising android TV BOX
Specification:
| The operating system |
Android4.0.3 |
|
| CPU type |
allA10 1.2GHz,Cortex-A8 |
|
| System memory |
DDR3 1GB(can choose) |
|
| NAND Flash memory |
Nand,The standard 4GB(can choose) |
|
| The menu language |
Support Chinese.English |
|
| Interface |
USB2.0*2,mini-SD, HD MI,RJ45,CVBS |
|
| Card type |
RJ45 100/1000M Network adaptive ,built-in WIFI 802.11b/g/n |
|
| Touch type |
Supports multi-touch, optical, acoustic, resistors, capacitors, and the infrared touch screen |
|
| Input output |
USB keyboard/mouse, ID card/unionpay card/bar code to read and write, password, keyboard, camera, the microphone |
|
| Storage type |
mini-SD card ,Usb |
|
| The file format |
video |
720P,1080P Hardware decode ,H263/264/MPEG4,AVI,WMV,MP4,MOV,FLV,RMVB and so on The mainstream media |
| picture |
JPG,JPEG,BMP,GIF,PNG |
|
| audio |
MP3,WMA,AAC,AC3,DTS |
|
| Support the resolution |
The highest support 1080 p hd video |
|
| Automatic switch machin |
Boot automatically by the cloud hairnet remote set period of time, turn it off |
|
| Play the way |
Through the cloud hairnet online choreography, distribute programs which can realize the horizontal/vertical screen play, timing, automatic playback ,media box |
|
| audio |
2.0 2*2w (8Ω)stereo |
|
| Program update |
Cloud hairnet remote online update, the local broadcast |
|
| Version update |
Cloud hairnet on-line automatic upgrades, local upgrades |
|
| Power |
12V DC |
|
Interface & parameters
1) Other standard interface
| Interface type |
Standand interface |
Note |
|
| Storage interface |
SDcard |
Data is stored, the maximum support 32 gb |
|
| USB*2 |
The HOST interface, support for data storage, data import, USB mouse and keyboard, camera, touch screen, etc |
||
| Ethernet interface |
RJ45 interface |
Support cable network |
|
| HD MI interface |
Standand interface |
Support HD MI output data, the maximum support 1080 p |
|
| CVBS interface |
Standand interface |
Support CVBS video output and the left and right sound channel output |
|
2)Electrical properties
| Project |
minimum |
A typical |
maximum |
|
| The power supply voltage |
Power |
-- |
12 |
-- |
| ripple |
-- |
-- |
50mV |
|
| Power supply current (HD MI output, did not meet other peripherals) |
Work Current |
-- |
250mA |
300mA |
| Standby current |
-- |
32mA |
40mA |
|
| USB power supply Current |
-- |
-- |
500mA |
|
| LCD power supply Current |
-- |
-- |
1A |
|
| Environment |
Relative humidity |
-- |
-- |
80% |
| Working temperature |
0℃ |
-- |
40℃ |
|
Working storage environment and use requirements
Please do not touch the board with his hands, and not by weight
Please access to the 12 v DC stable DC power supply
The ban on direct sunlight and prevent rain
The air humidity is < 95%
Working temperature: 0°C ~ 40 °C
Storage temperature: - 20°C ~ 60 °C
