Ultra-slim DIN rail PSU. 12VDC output, 7.1A rated current output, 85.2W rated power output.

Features

• Ultra-slim design with 52.5mm (3SU) width
• Universal input 85-264 VAC (277VAC operational)
• No load power consumption < 0.3W
• Isolation class II
• Pass LPS (limited power source)
• DC output voltage adjustable
• Protections: Short circuit / Overload / Over voltage
• Cooling by free air convection (working temperature -30°C to +70°C)
• DIN rail TS-35/7.5 or 15 mountable
• Over voltage category III
• LED indicator for power on
• 3 years warranty

Need technical help? Not sure if this will be compatible? Please give us a call.

*Next working day delivery on orders processed by 2.30 PM GMT
*VAT invoices are available



DC Voltage	12V
Rated Current	7.1A
Current Range	0 ~ 7.1A
Rated Power	85.2W
Ripple & Noise (max.)*	120mVp-p
Voltage Adj. Range	Pass LPS: 12 ~ 13V Non LPS: 12~ 13.8V
Voltage Tolerance**	±2.0%
Line Reguglation	±1.0%
Load Regulation	±1.0%
Setup, Rise Time	500ms, 50ms/230VAC 500ms, 50ms/115VAC at full load
Hold Up Time	30ms/230VAC 12ms/115VAC at full load
Volatage Range	85 ~ 264VAC (277VAC operational) 120 ~ 370VDC (390VDC operational)
Frequency Range	47 ~ 63Hz
Efficiency (Typ.)	88%
AC Current (Typ.)	0.88A/115VAC 0.48A/230VAC
Inrush Current (Typ.)	COLD START 25A/115VAC 45A/230VAC
Overload	105 ~ 160% rated output power
Over Voltage	14.2 ~ 16.2V
Working Temp.	-30 ~ +70°C
Working Humidity	20 ~ 90% RH non-condensing
Dimensions	70 x 90 x 54.5mm (W*H*D)

* Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μf & 47μf parallel capacitor.

** Tolerance : includes set up tolerance, line regulation and load regulation.
