Application
For Toyota 7A-FE 1.8L Engine
For Toyota Celica 1.8L (16 Valves) 1993-1997
For Toyota Corolla 1.8L (16 Valves) 1993-1997
For Geo Prizm 1.8L (16 Valves) 1992-1997
Notice: Pin Type: Floating Pin Piston

Dimensions
Connecting Rod Length Centre to Centre: 132.50mm/5.217in
Approximate Single Rod Weight: 509g
Big End Bore Diameter: 51.00mm/2.008in
Small End Wrist Pin Bore Diameter: 20.00mm/0.787in
Big End Width: 21.80mm/0.858in
Small End Width: 21.80mm/0.858in

Specifications
Beam Style: H-beam design for road and track use
Material: 4340 Chromoly Steel
Surface Finish: Shot-peened
Wrist Pin Fitment: Floating
Machined clearance compatible with stroker crank kits: Yes
Rod Cap Fastening: Through-bolt construction
Connecting Rod Bolt Brand: ARP
Bolt Diameter: 3/8"
Bolt Material: Alloy Steel
Standard Fastener Yield Strength: 220,000 psi (ARP 2000 Series)
Optional Upgraded Fasteners: ARP L19 (260,000 psi)
Bolt Head Format: 12-point
Machining: High Precision CNC Machined
Rod Cap Positioning: Precision alignment dowels
Bore Machining Tolerance: ±0.005 mm
Balancing Tolerance: ±1 gram per individual rod
Fully Weight Matched Complete Set: Yes
Condition: Brand New, Non-Remanufactured
Quality Control Tests: Magnaflux crack detection, X-ray inspection, ultrasonic material testing
Manufacturing Process: Fully heat treated

Performance Ratings
Rated Horsepower Per Rod: 200HP
Safe Maximum Operating RPM: 9,000rpm

Packaging
Quantity Supplied: Complete set of 4 connecting rods
Outer Package Dimensions: 28CM × 20CM × 10CM
