Fiber alignment
|
Core/cladding alignment / Manual alignment
|
|
Splicing time
|
6s
|
|
Heating time
|
15s
|
|
Heating mode
|
Automatic heating (Preheating)
|
|
Focus mode
|
Six motors Auto focus
|
|
Applicable Fibers
|
SM(G.652&G.657),MM(G.651),DS(G.657),NZDS(G.655)
|
|
Splice Loss
|
0.025dB(SM) 0.01dB(MM) 0.04dB(DS/NZDS)
|
|
Control technology
|
Real-time control and calibration of fusion ARC
|
|
Return Loss
|
Better than 60dB
|
|
Fiber diameter
|
Cladding Diameter: 80-150um Coating Diameter:100-1000um
|
|
Fiber Cleave Length
|
Coating less than 250um: 8-16mm Coating less than 250-1000um:16mm
|
|
Built-in lighting
|
Easy for night operation
|
|
Tension Test
|
Standard 2N
|
|
Fiber holders
|
3 in 1 fiber holder, SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable
|
|
Magnification
|
300 for X or Y view, 150 for X or Y view
|
|
Screen
|
5 inch TFT color display
|
|
Splicing Mode
|
Normal / high precision splicing
|
|
Splicing record storage
|
Synchronize to the phone, the server to cloud storage unlimited
|
|
Built-in battery
|
7800 mA high-capacity lithium battery, charging time ≤3.5 hours,
continuous splicing and heating about 240 times
|
|
Power supply
|
Input AC 100-240V 50/60HZ, output DC 13.5V/4A, the current power mode can be identified,real-time detection of battery power
|
|
Operating Conditions
|
Temperature: -15~+50°C, humidity: <95% RH(no condensation)
Working altitude: 0~5000m, resist max, wind speed: ≤ 15m/s
|
|
Shrinkable tube
|
60mm,40mm
|
