Please note that because the handlebar has a
-10
degree inclination, it will cause the fork hole to be sloping downward from the center of the handlebar, and there will be an extension surface, so the method of measuring stem length from the front cannot be used. What we recommend is the
back C-C
measurement!
Brand: SYNCROS
Material: carbon fiber
Applicable: road bike
Cable routing: internal/external
Spacers Material: Plastic
Top cover material: aluminum alloy
Handlebar size:(Mainly measured from the top C-C)
360(380)x80/90/100/110mm
380(400)x80/90/100/110/120mm
400(420)x80/90/100/110/120mm
420(440)x80/90/100/110/120mm
440(460)x80/90/100/110/120mm
Stem Length: 80/90/100/110/120(Back C-C.)
Stem Clamp Diameter: 28.6MM
Stem Outsweep: -10°
Reach: 77MM
Drop: 127mm
Weight: 377±5g (420x100)
