17 inch stroke linear actuator 1050LBS ACME screws

Dear Sirs/Madams,

If you want to buy our linear actuator,please leave your message on voltage and speed you need .If you don't choose voltage and speed within two days after you paid ,we will send you a linear actuator with a voltage of 12V,and the slowest speed 6mm/s with strongest force 4775N.

Please understand us ,and select the voltage and the speed when you buy .

MINIATURE LINEAR DC ACTUATORS

LINEAR DC ACTUATORS

Small motor actuator with ACME screws,built-in Micro

switch and an internal diode,can automatically stop and

enables the change of direction by simply reversing the

applied voltage polarity.stroke length can been customized.

switches are not made to be adjustable.Inversely proportional

to the speed and power.

MECHANICAL DATA

•Operating temperature -26°C~+65°C

•Aluminium outer tube and stroke rod

•Protection IP54

•12 or 24 DC •Aluminium alloy housing

•Preset limit switches •Low price

FORCE DATA

•Max load 5000N

•Duty cycle 20%(High-speed linear 10%)

L1=retracted length

DIMENSIONAL DRAWING

Stroke(±2 mm)                  50   100  150  2 00  250  300        350    400     425    450     500

Retracted length                225   275  325  375  425  475       525    575     600     625      675

 (L1)(±2 mm)



Weight (kg)                     1.6   1.8   1.92  2.02  2.2  2.4

Speed:

   6mm/s--------4775N(1050LBS)

   10mm/s-------2775N(610LBS)

   16mm/s--------1775N(390LBS)

   25mm/s--------775N(346LBS)
