Material

Carbon Firbre-Toray T700/Basalt braking surface

Size

700C

Appearance

3K

Finish

Matte

Rim depth

38/50/60/88mm

Rim width

23mm

Brake Line Width

13mm(basalt braking surface)

Rim type

Clincher

Wheel Out Diameter

633mm

ERD

568/544/524/468mm

Assembly Hole Dia

7.5mm

Spoke Hole Dia

4.5mm

Valve Hole Dia

6.5mm

Flatness

<0.2mm

Roundness

<0.5mm

Maximum Tire Pressure

120psi

Spoke Tension Front

100-130kg

Spoke Tension Rear

100-130kg (Non-Drive Side) 150-180kg(Drive Side)

Yaw

0.2mm

Weight

38mm Clincher:1470g/Pair+/-30g excluding skewers and brake pads

50mm Clincher:1570g/Pair+/-30g excluding skewers and brake pads

60mm Clincher:1640g/Pair+/-30g excluding skewers and brake pads

88mm Clincher:1870g/Pair+/-30g excluding skewers and brake pads

Maximum Weight

200kg*2 (front and rear)

Hub

Powerway R13 Hub(Black)

Spoke holes

20-24H

spoke color

CN 494 (Black)

Nipple color

Alloy CN nipples (Black)

Quick release(skewers):

Inclued(Balck)

Fit frame

For road bike

Casette body

(fit for shiman0 8/9/10/11 speed)

Warranty

1 year

Quality control

All pass EN standard test
