Type: Safety Relay

Model: UE48-30S2D2S1

Operating data:

Voltage supply A1, A2

Output circuit > 25 V AC / 60 V DC PELV

Output circuit ≤ 25 V AC / 60 V DC PELV or SELV

Supply voltage Vs A1, A2

24 V AC/DC (20.4 V AC/DC ... 26.4 V AC/DC)

Control voltage: S11, S21, S33:

Control voltage 22 V DC (≥ 17.4 V DC)

Control current 40 mA ... 100 mA

Short-circuit current ≤ 300 mA, between S33 / S11 and S21

Short-circuit protection Electronic fuse

Galvanized decoupling – (between A1, A2 and S11, S21, S33)

Input circuits: S12, S22, S31, S34, S35:

Input voltage

HIGH 17.4 V DC ... 26.4 V DC

LOW –3 V DC ... 5 V DC

Input current

S12, S22, S31 ≤ 100 mA

S34, S35 ≤ 50 mA

Reset time

Manual ≤ 40 ms

Automatic ≤ 80 ms

Activation time of reset button ≥ 50 ms

Output current paths: 13/14, 23/24, 31/32, 33/34:

Response time ≤ 25 ms 1)

Number of enabling current paths (N/O) 2, relevant for safety

Number of signaling current paths (normally closed) 1, not safety-relevant

Contact type Positively driven

Contact material Silver alloy, gold flashed

Switching voltage

Enabling current path 10 V AC ... 230 V AC

                                        10 V DC ... 300 V DC

Signaling current path 10 V AC ... 230 V AC

                                        10 V DC ... 300 V DC

Package Include:

1 * Safety Relay
