Features:
Widely Compatible Design: The SCULPFUN module has a clever and widely compatible structural connection device, which can be well adapted to different engraving machines, cutting machines, 3D printers, CNC milling machines, etc. It can be installed on a variety of brand machines, such as SCULPFUN, , engraving machine, or other DIY type machines.
High Performance Beam: S9 uses the latest 5.5W beam shaping technology ,the effect of this technique is to get a super-high-density energy beam , it is more than just a , the entire beam is very thin. It has an ultra-fine 0.06mm , with super cutting penetration and , he can cut up to 15mm thick wood, 10mm acrylic, carve ceramics and stainless steel, this is almost beyond the effect of 90W CO2 .
Fast Fixed- Design: The S9 module has the fastest ing design on the market. It combines a fixed lens and a sliding design. You only need to slide the and tighten the screws to complete ing. This makes the use of the very simple. Using it on different machines does not affect its sliding fixed ing function.
Eye-protection Design: The filter cover filters 98% of the ultraviolet light to the eyes. You and the people around you can watch engraving from all angles without wea goggles. At the same time, it can prevent animals from catching the spot.
General 12V/PWM Modulation Board: It uses a common 12V/PWM modulation board, which can be adapted to common GRBL or CNC motherboards. You can view product pictures for details.
Specifications:
Model: SCULPFUN S9 Module
Applicable Machines: engraving machines such as SCULPFUN, , , ELEKSMAKER, or DIY 3D printers, CNC machine tools.
Engraving Materials: Paper, cardboard, plastic, white, PCB board, alumina, stainless steel, black metal, ceramic
Cutting Material: Thin board, acrylic board, cardboard, non-woven fabric, bamboo, some plastic board;
Output Power: 5.5-6W (light energy)
Wave Length 455±5nm
Type and Fixed Method: fixed , fixed through 20mm measu column
Protective Cover: The -shaped violet filter cover protects the user's eyes and prevents animals, etc. from contacting the spot.
Shell Material: Aluminum alloy
Packing Size: 11*12*18cm
Package Weight: 0.5kg
Circuit Board Parameters:
Circuit Board Size: 40*40mm
Circuit Board:12V/PWM modulation board
Input voltage: 12V
Input of module:12V 3A
Wire Rod:HY2.0, 3Pin terminal (3-core cable, A: PWM +, B: GND, C: VCC ).
Fan:12V 0.15A 4020 fan
Fan speed: 10000 rpm
Operating Temperature: -20 ℃ to 70 ℃
Precautions:
●For detailed machine instructions, please refer to the manual for parameter settings.
●Before installing and using the , you should understand the adaptability and the imum input voltage and current to avoid damage to the .
●Do not touch the with your hands, otherwise you may burn your hands.
●Please avoid strong impact on the machine.
●It is forbidden for children under 14 years old to use this product. Children over 14 years old need adult supervision.
●Do not apply the directly to any specular reflection object, which may cause injury to the operator or burn the .
Package List:
head*1
Multi-function Structural Connection Device *1
20mm Measu Column*1
Screws Tool Kit*1
