Description

Notice:

Please double check the diameter of driver shaft and the Length of Drive Shaft / Crankshaft !!!

Diameter of Drive Shaft: 20 mm / 0.79 inches (NOT 0.75 INCH, NOT 3/4'' )

Typical Application for:
Compressor Scarifier Lawnmower Pump Generator Pressure Washer Gokart Lawnmower Cement Mixer Dust Collector Flail Mower

Technical Data:

Compression Ratio : 8.5:1

Engine Type : 168F/ Air Cooled 4 Stroke OHV Single Cylinder

Maximum Output : 5.5 HP / 4.1 KW

Rated Output : 4.0 HP / 3.0 KW
Bore & Stroke : 70x55mm
Displacement : 168cc

Starting System : Pullstart

Fuel Capacity : 3.6 Litres
Engine Oil Capacity : 0.6 Litre
Overall Length: 360 mm / 14.17 inches
Overall Width: 305 mm / 12.01 inches
Overall Height: 330 mm / 12.99 inches
Length of Drive Shaft / Crankshaft: 250mm / 9.84 inches

Distance Between Bottom Fixing Holes (Clutch Side, Centre of Eye to Centre of Eye): 165 mm / 6.5 inches
Distance Between Bottom Fixing Holes (Pullstart Side, Centre of Eye to Centre of Eye): 165 mm / 6.5 inches
Distance Between Bottom Fixing Holes (Pullstart to Clutch across, Centre of Eye to Centre of Eye): 77.06 mm / 3.03 inches
