DS4T252 Kit (50M/200MSa/s/2Mpts) Portable Handheld Mini Dual Channel Oscilloscope with 4.3-Inch IPS Touch Screen

Introduction:
- Using the same hardware architecture as a desktop oscilloscope, the core consists of a powerful FPGA hardware waveform processing engine and DRAM storage, rather than a software implementation based on MCU.
- Providing multiple interpolation methods to perfectly restore high-frequency square waves.
- Storage depth up to 2Mpts, maintaining the same storage depth at full horizontal resolution. The signal collected with this oscilloscope can be enlarged and reduced horizontally at any resolution after stopping, perfectly reproducing the desired waveform.
- Adopting for EPSON high-precision low-temperature drift crystal oscillator and hardware real-time frequency measurement.
- We have designed a complete set of "single finger touch" operation methods, simplifying all functions into 1-3 steps of light touch and sliding operations, without having to search for buttons and menus everywhere. Tap twice to add/remove a measurement option. Provide 20 automatic measurement options. The horizontal resolution supports single finger sliding adjustment of the entire waveform area, while the scroll wheel area supports quick drag and drop adjustment. Provide rich channel control options in the vertical direction, offer roller adjustment, and support drag and drop for quick adjustment.
- Supports storage and loading of up to 9 configurations, allowing for one click switching between different measurement scenarios.
- Seamless integrated soft rubber wrapping + hard plastic support shell design, with four corner anti-collision protrusions. The front screen has a wear-resistant protective strip.
- Comes with a bracket design that supports different elevation angles for support.
- Fanless design, rejecting noise, quiet thinking.
- 6-hour battery life, supports sleep mode without operation.

Package Included:
- 1 x Oscilloscope
- 2 x Testing Probes
- 1 x USB Charging Cable
- 1 x RF Cable
- 1 x Carrying Bag
