Product Overview
MF511Portable WiFi
Karbor MF511 features a powerful wireless chipset: MT6877; WiFi chipset: MT6635, delivering stable signals with secure and reliable performance. The MT6877 features an octa-core CPU, including two Arm Cortex-A76 cores clocked at up to 2.2GHz. Manufactured using a 6nm process, it delivers both high performance and low power consumption, significantly extending battery life. Supports 5G high-speed transmission and is compatible with dual-band 2.4GHz/5GHz WiFi standards. Can be customized to support European/Asian frequency bands and American frequency bands as required. The product has obtained CE/FCC certification and meets the safety certification requirements for wireless devices to enter the market.
Features At A Glance
Type-c USB
Rear view
Product 6-sided image
Product Specifications
|
NO
|
Item
|
Data
|
|
1
|
Model No
|
MF511
|
|
2
|
Support network
|
5GNR:n1/n3/n5/n7/n8/n20/n28/n26/n66/n38/n40/n41/n48/n77/n78/n79 or 2/5/12/25/66/41/77/78/79
LTE:B1/B3/B5/B7/B8/B20/B28/B32/B38/B46/B11/B18/B19/B21/B26/B34/B39/B40/B41/B42/B48 or 2/4/5/7/12/13/14/25/26/17/41/66；
WCDMA:B1/B2/B5/B8 or 1/2/4/5/8；
|
|
3
|
Chipset
|
Wireless chipset:MT6877
WiFi chipset:MT6635
|
|
4
|
WiFi
|
2.4GHz+5GHz 802.11a/b/g/n/ac/ax
|
|
5
|
MIMO for Wireless
|
LTE MHB DL 2*2MIMO,
LTE LB DL 2*2MIMO
LTE LMHB 1*1 SISO
5G NR MHB DL 4*4 MIMO,
5G NR LB DL 2*2 MIMO
5G NR UL 1*1 MIMO
|
|
6
|
MIMO for WiFi
|
2.4G 802.11.b/g/n MIMO 1*1
5G 802.11.ac MIMO 1*1
|
|
7
|
Wireless rate
|
5G NR DL: 2.77Gbps (4*4 MIMO, 256QAM)
5G NR UL: 1.25Gbps (1*1 MIMO, 256QAM)
LTE: DL: UP to 391Mbps, UL: 150Mbps
|
|
8
|
Battery
|
Li-on 5000mAh Removable
|
|
9
|
USB Port
|
Type-C
|
|
10
|
WiFi Max Client
|
Up to 16 connected users
|
|
11
|
SIM Slot
|
Nano SIM Card (4FF)
|
|
12
|
OS
|
Android 11
|
|
13
|
Memory
|
2GB NAND Flash +8GB LP DDR4
|
|
14
|
Display
|
2.4 inch LCD display
|
|
15
|
Size
|
129*68.8*20.8mm
|
