Details
Product size and performance parameters:
Resonant frequency (KHz): 40 ± 1
Static capacitance (pF): 8500 ± 10%
Resonance impedance (Ω): ≤20Ω
Dimensions: 50 * 2.6mm (diameter * height)
Power (W): 35w
Insulation resistance (2500V DC): ≥ 100MΩ
Features
1. Low heat.
2. Good thermal stability.
3. Frequency and static capacitance strong consistency.
4. Resonant impedance is low.
5. The average length of life.
6. It can be widely used in a variety of ultrasonic cleaning equipment.
7. High performance: mechanical Q value, high vibration efficiency
Special Note
Received ceramic sheet is not terminal and connecting terminals
