HDMI to USB3.0 Video Capture Adapter 4K 1080P Dongle Card Live Streaming
Features:
Compact design, portable and easy to carry.
It is compatible for Windows, for Linux, for OS X and USB 3.0 interface, and is compatible with many USB 3.0 chipsets (for Intel, for Renesas, for ASMedia, for Fresco Logic), compatible for PCIe gen, and is expanded by 3.0 interface.
UVC and UAC standard. Plug and play, no external driver required.
It can automatically detect the input video format and automatically adjust to the set output size and frame rate.
Can capture one single channel HD HDMI video signals and support the resolution of Input and Output Video Signal up to 1080P at 60Hz.
It supports UVC video capture and YUV 422 video output.
The process of video and audio is done by the dongle and will not occupy the CPU.
Specifications:
Material: Aluminum Alloy
Host Interface: USB3.0, 300-350MB/s, USB2.0, 40MB/s
Input Interface: HDMI Interface support 4K 30Hz
HDMI Input Format: 480i, 480p, 576i, 576p, 720p50, 72060, 1080i50, 1080i60, 1080p24/25/30/50/60;
Output Format Resolution: 640 x 480 / 720 x 480 / 720 x 576 / 768 x 576 / 800 x 600 / 1024 x 768 /1280 x 720 / 1280 x 800 /1280 x 960 / 1280 x 1024 / 1368 x 768 / 1440 x 900 / 1600 x 1200 / 1680 x 1050 / 1920 x 1080 / 1920 x 1200 / 640 x 360 / 856 x 480 / 960 x 540 / 1024 x 576
Frame Rate: 25 / 29.97 / 30 / 50 / 59.94 / 60 fps
Audio and Video Capture: UVC and UAC standards
Supported Operating Systems: for Windowsn 10 / for Windows 7 / for Windows Server 2008 R2 /for Linux (for Kernel version 2.6.38 and above) / for OS X (10.8 and above)
Software is not included, you might need player such as VLC Media Player or other recorder
Power: 5V USB (power adpater not included)
Package Includes:
1 x HDMI to USB3.0 Video Capture
1 x USB 3.0 Cable
1 x HDMI Cable
Software is not included, you might need player such as VLC Media Player or other recorder
