Function & Introduction:

- Function: Scaling & Perio & Endo & Sand blasting & Implant Maintain
- Smart,sensitive touch sysem,waterproof IML touch operation panel.
- Wireless foot control,new water regulating design at the handpiece.
- 700ml high capacity water bottle×2pcs,anti-corrosion design,unique LED guiding light of water
bottle.
- Handpiece intelligent recognition system to change the model automatically or give the points.

Specifications:

- Input AC100~240V,50/60Hz
- Main Unit Input DC30V,1.3A
- Water Input pressure 0.5MPa~0.6MPa
- Vibration frequency of the tip 28kHz+3kHz
- Ultrasonic output power 3W~20W
- Output Half-excursion 2N
- Foot Switch Batteries 1.5V×2
- Receiving Sensitivity -114Db
- Main Unit Dimensions 310×370×170mm
- Packing Size 470×400×235mm
- Weight of main unit 1.50kg
- Gross Weight 8.5kg
- Quality guarantee host-3 years,handpiece-1 year

Packing list:

Main Unit x 1
Water Tank x 2
Wireless Foot Swtich x 1
Foot Switch with wire x 1
Sandblasting handpiece x 2
Sandblasting Handpiece Tip x 1
Subgingival Sandblasting Part x 1
Subgingival SandblastingTip x 40
PH-2 LED Scaler handpiece x 2
Disinfection Box x 2
Power Adaptor x 1
Power Plug x 1
Instruction manual x 1
OC Certificate x 1
Packing List x 1
Waterproof Sticker x 1
Scaler Tips x 22
20#Endo File x 6(20#)
25#Endo File x 6(25#)
Three-way Valve x 1(6-6-6mm)
Quick Connector x 1(8-6mm)
Three-way Quick Connector x 1(8-6-8mm)
Internal Shut-Off Valve x 1
Endo File Wrench x 1
Torque Tip Wrench x 2
Goggles x 1
PU Pipe 8*6mm*0.5mm x 1(0.5mm)
PU Pipe 4*6mm*2mm x 1(2mm)
Niddle 1.0mm x 1
Niddle 0.5mm x 1
O Ring x8(3*1,4*1,6.5*1.2,12.5*1)Two of each of the four models
Fuse x 1

ScalingTips:G1*1,G2*1,G3*1G4*1,G5*1,E1*1,IM1*1,P1*1,P2R*1,P2L*1, P3*1,P11*2,P12L*2,P12R*2P12*2,P13R*1,P13L*1,P15*1
