Processor
Supports 9th/ 8th Gen Intel® Core™ / Pentium® Gold/ Celeron® processors for LGA 1151 socket

Chipset
Intel® Z390 Chipset

Memory
4x DDR4 memory slots, support up to 128GB
Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) /2800(OC)/ 2666/ 2400/ 2133 MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)

Expansion Slots
2x PCIe 3.0 x16 slots, support x16/ x4 mode
3x PCIe 3.0 x1 slots
1x M.2 slot (Key E) for an Intel® CNVi wireless module only
Onboard Graphics
1x DVI-I port, supports a maximum resolution of 1920x1200@60Hz
1x DisplayPort, supports a maximum resolution of 4096x2304@60Hz
Multi-GPU
Supports 2-Way AMD® CrossFire™ Technology
Storage
Intel® Z390 Chipset
6x SATA 6Gb/s ports
2x M.2 slots (Key M)
M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices
The SATA2 will be unavailable when installing M.2 SATA device into M2_1 slot.The SATA5 & SATA6 will be unavailable when installing M.2 PCIe/ SATA device into M2_2 slot.
USB
Intel® Z390 Chipset
2x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port) on the back panel
8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB 3.1 connectors)
4x USB 2.0 (High-speed USB) ports available through the internal USB 2.0 connectors
The CNVI_1 and JUSB2 share the same bandwidth. Please refer user manual for details.
Audio
Realtek® ALC892 Codec
Realtek® ALC892 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN
1x Realtek RTL8111H Gigabit LAN controller
Internal connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
6x SATA 6Gb/s connectors
3x M.2 slots (2 M-Key slots,1 E-Key slot)
2x USB 3.1 Gen1 connectors support additional 4 USB 3.1 Gen1 ports
2x USB 2.0 connectors support additional 4 USB 2.0 ports
1x Clear CMOS jumper
2x Front panel connectors
1x TPM module connector
1x Chassis Intrusion connector
1x Front panel audio connector
1x 4-pin CPU fan connector
1x 4-pin Water Pump connector
4x 4-pin system fan connectors
1x Thunderbolt Add-on card connector
