T-Type Three-Output Shaft 2.5 Module 16 Teeth 90-Degree Reversing Gearbox Reverse Direction Compact Right-Angle Gearbox

Product Name: 2.5-module 16-tooth right-angle gearbox
Specification Model: 2516L-LZXQ-20
Housing Material: Aluminum alloy, nylon upper/lower covers
Gear & Shaft Material: 45 steel with hardened tooth surfaces, stainless steel shaft + zinc-plated shaft
Shaft Diameter & Length: ∅20x35
Mounting Orientation: Horizontal
Number of Shafts: Two
Rotation Direction: Reverse, Same-Direction
Operating Speed: Below 1000 RPM
Unit Weight: 1.25 kg
Gear Radial Load: 20 Nm
Surface Finish: Spray-painted Flash Silver
Product Name: 2.5-Modulus 16-Tooth Right-Angle Gearbox
Specification Model: 2516L-TZXQ-20
Housing Material: Aluminum alloy, nylon top/bottom covers
Gear & Shaft Material: 45 steel gear teeth with hardened stainless steel shaft + zinc-plated shaft
Shaft Diameter & Length: 020x35
Mounting Orientation: Horizontal
Number of Shafts: Three
Rotation Direction: Reverse, Same-Direction
Operating Speed: Below 1000 RPM
Unit Weight: 1.3 kg
Gear Radial Load: 20 Nm
Surface Finish: Spray-painted Flash Silver
