Professional 8 channel dj mixer digital audio eco mixing

Fashion and Durable Chassis Design:Ultra-fashion of all metal chassis design, high dynamic, low noise design of mixer,high quality microphone preamplifier, high density dust and durable.

Multi-format Play Support: Can connect mobile phones, tablets, etc.With digital display MP3(U-DISK MP3 input),MP3 with REC.

Mono/Stereo Channels EQ: Mono 4-band EQ design (High, Mid-high, mid-low,low), High resolution stereo level with 12 pieces of LED lamps.

Built-in Many commonly used Effects Processor: Built-in 16 kinds of DSP effects with high quality,CD/ mobile phone multi input source matrix.

Other Fatures:FX returns function,Each channel with mute switch,AUX sends channel function, 48V phan-tom power supply condenser microphone, The universal power supply(100-240V).











FEATURES:

New ultra-low noise-design with highest possible headroom

6-16 studio-grade XDR2 Extended Dynamic Range mic preamps with:

Uitra-wide 60db gain range

130db dynamilc range

+22dbu Iine Input handing

Extended low frequency response

Distortion under 0.007%THD(20hz-20khz

Phan-tom power for studio condenser mics

6-16hlgh-headroomllne Inputs(1 stereo pairs, 16 mono)

Advanced DC pulse transformer RF rejection

60mm long-wearing logarithmic-taper faders

4x 2 Matrix Mixer

provides 2 additional mixes for cry rooms, monitors, etc.

1 Aux sends, level, pan, 20db/Solo and OL/Mute LEDS on each channel

1 stereo Aux retums, 32 Directouts

1 stereo Group/Bus outputs

4-band Active EQ on mono channels Stereo channel EQ

High 12KHZ

High mid 2. 5KHZ

Low mid 400 Hz

LOW 80 Hz

18db/oct.75HZ Lo-Cut filter on mic channels

Phones multi-input source matrix with separate level controls

Balanced 1/4"Inputs and outputs(except Inserts)

Sealed rotary controls to resist dust and grime

I New Multi-voltage power supply for world wlde use

rugged steel chassis

Bullt-in 24 bit tong sound digital effects processor

16 FX settings Tap Tempo



TECHNICAL SPECIFICATIONS:

Maximum levels

Outputs>100ohms

Mlc Input 30dbu

EQ(each band)±15dB

Line Input 21 dbu

Mono channel EQ

All other Input 22dbu High 12KHZ

Mixer Rated Output

High mld 2, 5khz

Main outs +4dbu

Low mid 400 Hz

ols All other outs+4 dbu Low 80 Hz

Maximum output 22 dbu Stereo channel EQ

Frequency response Low 80HZ

Mic Input to main output High 12hz

+0-1 db. <10HZ to 80KHZ

+0-3 db. <10hzto 120KHZ

Connectlon Impedance

Mic lnputs 2k ohms

Line Inputs >10k ohms
