AST PH-GRP075-1616 PLC-Controlled Meter-Mix-Dispense System AS-IS Pumps Seized
Manufacturer: Adhesive Systems Technology AST
Model: PH-GRP075-1616
Condition: For Parts or Not Working
- Residential area?
- Dock or forklift?
- Zip code?
*Shipping to be arranged by seller
Manufacturer: Adhesive Systems Technology AST
Condition: For Parts or Not Working. This system is in fair cosmetic condition. There are process, dirt, and adhesive label residues all over this machine.
Notes: This system is in PARTIAL working condition. We were able to use the touchscreen controls to command the pump motor to run, but the gear skipped on the chain; both pumps are locked up solid, full of old product. The red and amber lights on the stack tower both work. The e-stop button works. The wheels roll well enough, but the swiveling wheels don't swivel, so overall it rolls pretty poorly. The PLC's cumulative gallon totalizer reads 1796 gallons. No other testing was done.
No manuals, cords/cables, or additional items are included if not listed or shown.
Included:
- (1) AST PH-GRP075-1616 Dispense System
Specifications:
- Manufacturer: Adhesive Systems Technology Corp.
- Model: PH-GRP075-1616
- PLC-Controlled Meter-Mix-Dispense System
- Motor-driven geroller dispense pumps
- Pneumatic valves for product control
- Shot size: 100-3500 ml
- Shot rate: up to 40 gms/sec
- 1:1 mixing ratio
- 7.5:1 reduction chain drive for pumps
- Pumps are rated for 0.478 cubic inches per revolution
- Formerly used to dispense Henkel Polyurethane US5500 parts A & B
-
Programmable logic controller: 1766-L32BXB MicroLogix 1400 32 Point Controller with EtherNet IP interface
Human/Machine Interface: Allen bradley 2711R-T4T
Pump motor: Leeson C42D17FK7D
Gearhead: Grove Ironman GR-TXMQ-7.182-56C-56C - Pumps are seized! Sold AS-IS!
