Product Description
Introduction:
The machine is made of stainless steel, removable tool-free clean, simple and reasonable structure, The machine can be foot-operated or auto mode control filling. It is widely used in ,chemicals for daily use, food, pesticides and special industries.
Applications:
It is not only suitable for ketchup, detergent, honey and other paste, but also suitable for a variety of liquids, a wide range of uses.
Filling Principle:
The machine is a semi-automatic piston filling machine, which is driven by a cylinder to extract and eject material. The material flow is controlled by a three-way rotary valve. The stroke of the cylinder can be controlled by the reed switch. The filling volume can be adjusted, You can adjust the intake air cylinder to achieve rapid or slow filling.
Features:
1. This machine has two pneumatic filling ways, foot and automatic, and they can be switched randomly.
2. Parts in contact with materials are made of 304 stainless steel, in line with food grade requirements.
3. Its structure design is reasonable, small size, easy to operate.
4. There are filling volume adjustment handle, filling speed can be adjusted, filling high precision.
5.We can accord to customer's requirements to design the filling volume.
Filling Volume:
10-100ml, 30-300ml, 50-500ml, 100-1000ml, 200-1500ml,300-2500ml, 1000-5000ml.
|
Model
|
G1WGD100
|
|
Filling range
|
10-100ml
|
|
Product capacity
|
5-20 bots/min
|
|
Filling Accuracy
|
±1%
|
|
Air Pressure
|
0.4-0.6MPa
|
|
Required Air Compressor
|
≥1.5KW 65L
|
