Note:
We would suggest you to purchase our remote control for the better working performance.
Transfers distance: 10~100m.
If you need it to work with your own receiver, you must make sure 100% that your receiver is 433mhz Frequency,does your receiver have a learning button to learn the transmitter code? and does your receiver can be compatible with 1527 ic chip transmitter.
Every parcel only get 1 pcs cross screwdriver as a free gift whatever how many you order.
Toggle:Push once the remote button , the relay connects , push twice the remote button , the relay dis-connects .
Latching:Push the remote button A, the relay connects, push the remote button B, the relay dis-connect.
Time delay mode:Push the remote control button , the relay connects , from when release the remote button , after 5s or 10s or 15s or 20s , the relay disconnect automatically.
Learning the code :(momentary)
Push the learning key on the receiver once time , it comes into momentary setting mode .
Wait for a moment , the LED will be on, it comes into learning state .
Push the remote button , LED indicator on the receiver board will flash 3 times and then come off,
learning successfully .
Learning the code : ( Toggle )
learning successfully .
Learning the code :( Latching )
For example : button A = ON , button B = OFF
Push the learning key on the receiver triple time , it comes into latching mode .
Wait for a moment , the LED indicator on the receiver board will be on,
Push the remote button A,LED flash for 3 times .
Push the remote button B .Led indicator flash for 3 times and then come off,
learning successfully.
A = ON , B = OFF .
Learning the code :( Time delay mode )
Push the learning key on the receiver forth time , the time dealy for 5 seconds .
Push the learning key on the receiver fifth time , the time delay for 10 seconds .
Push the learning key on the receiver sixth time , the time delay for 15 seconds .
The LED indicator will be on .
Push the remote button , LED indicator flashes 3 times and then off, learning successfully .
Push the remote button,LED indicator on the receiver board will flash 3 times and then come off,
learning successfully .
NOTE: The system can store for 15 pcs of remotes , if the remote get more than 15 pcs , the initial remote control will be lost .
