Details
Features:
1.Mecha transparent design: cool transparent shell, full of sense of technology, show the beauty of internal structure
2. High-capacity support: compatible with 8 18650 batteries, providing long battery life, to meet the demand for high power 3. DC regulatable function: support the output voltage adjustment, adaptable to a variety of devices, flexible and practical
4. Welding-free installation: modular design, no welding, DIY assembly is simple and convenient.
5. Multiple safety protection: built-in over-charging, over-discharging, short-circuit protection, to ensure the use of safe and reliable!
Parameter:
PD + flash charging + super fast charging + fast charging version
Output power: 22.5W
USB output: 5V/3A,9V/2A,12V/1.5A (only 5V for multiple outputs at the same time)
DC (5.5*2.1) output: 5V/6V/7V/8V/9V/10/11V/12V (3A-1.5A) 18W
IN input: 5V/3A, 9V2AType-C output: 5V/3A, 9V/2A, 12V/1.5A (support PD protocol only output)
Type-C input: 5V/3A, 9V/2A, 12V/1.5A
Features: single-click to display power, double-click to turn on outdoor LED color light, long-press to switch DC mode/USB mode; output input real-time current and voltage display
Effective voltage: 3.3V-4.15V (spring with voltage drop)
Capacity requirements: the minimum real capacity of the battery pack can not be less than 10,000 mA, otherwise the power did not fall out of the battery has not actually discharged the electricity
If the cell phone private protocol is not supported (USB without fast charging), you can use PD charging (TYPE-C output), PD public protocol output is more stable
Fast charging specifications (support protocol).
Integrated SCP 22.5W super fast charging output protocol
Integrated 22.5W flash charging output protocol
Integrated QC4.0+/QC4.0/QC3.0/QC2.0 output fast charging protocols
Integrated FCP, AFC input/output fast charging protocols
Support PPS, PE2.0, SFCP output fast charging
Support PD3.0/2.0, PE1.1 input/output protocols
Battery Requirements: Flat head unprotected plate 18650 battery (65MM long), internal resistance within 40 mOhm, discharge 1C or more; fast charging and DC mode are very powerful, do not use poorer batteries, it will affect the experience, if the battery is not durable, or even the output power outage, please replace the battery immediately.
Package include:
Solderless battery case *1 (style of your choice)
