High-precision miniature gravity force measurement pressure sensor with digital display controller meter


Range
10、20、30、50、100、200、300、500、1000、2000kg
Sensitivity: 1.0~2.0±0.1mv/V
Comprehensive accuracy: ±0.02%F-S
Creep: ±0.02%F.S/30min
Non-linearity: ±0.02%F.S
Hysteresis error: ±0.02%F-S:
Repeatability error ±0.02%F-S
Zero temperature coefficient: ±0.02%F-S/10°C
Input Impedance: 385±35Ω
Output impedance: 350±3Ω
Insulation impedance: ≥2000MΩ
Excitation voltage: 5~12VDC
Operating Temperature Range: -30~+70°C
Allowable overload: 120%F-S
Sealing Grade: IP65
Material: stainless steel
Cable: Φ5x2000mm
